AIO FC SpeedyBee F745 35A BLS 25.5x25.5

Opis szczegółowy produktu

SpeedyBee F745 35A BLS 25.5x25.5 AIO Flight Controller

Speedy Bee's F745 35A BLHeli_S AIO Flight Controller is another option for the 3.5" to 5" cinewhoops/long-range.  This AIO features a powerful F745 MCU for smoother flights, durable 35A 6S Toshiba MOSFETs, BMP280 barometer, 8mb blackbox flash, and wireless support for both the flight controller and ESC through the Speedy Bee App.  Full Betaflight and BLHeli_S configuration out in the field using your phone.

Specifications:

MCU: STM32F722
IMU (Gyro): BMI270
USB Port: DM DP External USB
Barometer: BMP280
OSD: Supported
BLE Bluetooth: Supported
Flash FC Firmware Wirelessly: Supported
Download/Analyze Blackbox: Supported
DJI Air Unit Soldering Pads: Supported
Flash Memory: 8MB
Current Sensor: Supported, Scale=2900
Betaflight Camera Control: Yes(CC Pad)
Power Input: 3S - 6S LiPo
5V Output: 4 groups of 5V output. Total current load is 2.5A
9V Output: None
3.3V Output: Supported - Up to 500mA current load
ESC Signal Pads: M1 - M4
UARTs: 4 Full UARTS
ESC Telemetry UART: None
I2C: Supported
LED Pad: WS2812 LED Supported
Buzzer: 5V pads for Buzzer
Boot Button: For DFU Mode
SmartPort: Use and TX pad of UART for SmartPort feature
Firmware: Betaflight, EMUFlight, iNav
Target: SPEEDYBEE F745AIO
Mounting: 25.5 x 25.5mm, 3mm hole diameter
Dimensions: 36.5x36.5x7mm
Weight: 10.1g
