Receiver RadioMaster RP2 V2 ELRS 2.4GHz Nano

Opis szczegółowy produktu

RP2 V2 ExpressLRS 2.4ghz Nano Receiver (LBT)

The RP2 2.4GHz ELRS nano receiver is an open-source receiver based on ExpressLRS and features ESP8285 MCU and SX1280 RF chip. The RP2 has a built-in ceramic antenna which is super light and small in size and ideal for racing. It has built-in WIFI and is suitable for many models due to the ultra-light and Nano size.

Note: Available with standard ISM or EU LBT FW. EU LBT FW is required for use with Radios and Modules with EU LBT FW Installed.

Features:
- Improved PCB design is better for heat dissipation.
- LED on the top side of the PCB.
- Solder pads are improved and easier to solder to.
- Built-in a TCXO (temperature-compensated crystal oscillator)

Specification:
Item: RP2 Nano ExpressLRS 2.4ghz Receiver
Type: EU LBT FW
MCU: EPS8285
RF Chip: SEMTECH SX1281
Telemetry RF power: 10mW
Antenna: On Board SMT Antenna
Antenna: 65mm 2.4ghz T Antenna
Frequency Range: 2.404 - 2.479 Ghz
Maximum receive refresh rate: 500Hz/F1000Hz
Minimum receiver refresh rate: 25Hz
Working voltage: 5v
Weight: 0.55g (On Board antenna)
Dimension: 13x11x7mm
Firmware Version: ExpressLRS v2.4 pre-installed
FW Target: RadioMaster RP1/2 2400 RX
Bus interface: CRSF
