GPS Module Holybro H-RTK F9P Rover Lite

Opis szczegółowy produktu

GPS Module Holybro H-RTK F9P Rover Lite

This system provides multi-band RTK with fast convergence time and reliable performance, simultaneous reception of GPS, GLONASS, Galileo, and BeiDou, as well as high update rates for high-dynamics and large-scale applications with centimeter-level accuracy.

The Holybro GPS module is cost-effective, lightweight, and high-performance. It can significantly reduce the cost of large projects with many drones, such as light shows or surveying. The module features a built-in safety switch and a three-color LED indicator and is compatible with Pixhawk series flight controllers with open-source firmware.

Specifications:

• Application: UAVs
• GNSS:
  • GPS L1C/A (1575.42 MHz)
  • GPS L2C (1227.60 MHz)
  • GLONASS L1OF (1602 MHz)
  • GLONASS L2OF (1246 MHz)
  • BeiDou B1 (1561.092 MHz)
  • BeiDou B2 (1207.140 MHz)
  • Galileo E1-B/C (1575.42 MHz)
  • Galileo E5b (1207.140 MHz)
• Antenna Peak Gain (MAX):
  • L1: 4.0 dBi
  • L2: 1.0 dBi
• Typical LNA Gain:
  • 20.5+1 dB
• Time to First Fix:
  • Cold Start <29 s
  • Hot Start <1 s
• RAW:
  • Max. 20 Hz
  • RTK Max. 8 Hz
• Port:
  • 26 cm, compatible with Pixhawk4
  • GH1.25 10-pin cable included / 6-pin cable
• Connector:
  • SMA
• Data Transmission Rate:
  • 115200 5 Hz (default, adjustable)
• Operating Voltage:
  • 4.75V-5.25V
• Diameter:
  • 76 mm
• Height:
  • 20 mm
• Weight:
  • 106 g

Package Includes:

• GPS Holybro H-RTK F9P Rover Lite
• H-RTK F9P Rover Lite 2nd GPS (optional)
• Fixed GPS Mount with Carbon Fiber (40 mm)
• GPS UART to USB Converter (for SKU12017)
• USB Cable (Type-C)
