FPV Drone GEPRC CineLog25 Analog ELRS 2.4G

Opis szczegółowy produktu

CineLog25-Analog-ELRS 2.4G

The CineLog25 is a lightweight quadcopter designed for capturing video with a GP Lite camera. Its propellers offer optimal flight efficiency. The VISTA HD is centrally positioned for smooth airflow and reduced noise. Redesigned the camera mount's shock absorption system and provided damping rings for vibration control. Using 3, 4, or 5 damping rings, you can fine-tune the vibration and noise stability according to your flight conditions. The CineLog25 has a pusher frame, that combines ultra-light carbon plates and advanced materials, resulting in a 20% strength increase and 15% greater efficiency.

The flight system includes the F411-35A AIO and upgraded GEPRC GR1404 4500kv motors. The power system works with 450mAh to 750mAh batteries for a 5.5-minute flight time. Customized EVA foam cushioning protects during crashes.

Features:

1. Improved power efficiency with the GR1404 4500kv (Upgraded Version) power output scheme and precise tuning provide extended flight times.
2. Perfectly compatible with popular cameras such as SMO 4K, GP6 Lite, and GP8 Lite, offering versatility for your shooting needs.
3. Adjustable lens angle from 0-40 degrees.
4. Camera power line output: Dedicated power cable output to the camera (GP6 & GP8), with Video Recording Wire, allowing direct control of camera power via the remote controller.

Specifications:

Brand: GEPRC
Frame: GEP-CL25
Wheelbase: 109mm
Flight Controller: F411-35A AIO
MCU: STM32F411
Gyro: 6-Axis
OSD: BetaFlight OSD w/ AT7456E chip
ESC: BLheli_S 20A
VTX: 5.8G 600mW VTX
Camera: Caddx EOS2/Runcam Nano2
Props: GEMFAN D63-3
Motors: GR1404 4500kv (Upgraded Version)
Antenna: GEPRC Momoda 5.8g RHCP
CineLog25 Analog Weight: 128g (Without battery)
Receiver: ELRS 2.4G
Battery: Recommended 4S 450-750mAh or GEPRC 4S 660mAh 90/180C HV 3.8V/4.35V LiPo Battery
