FPV camera CADDXFPV ECLIPSE 006HD Thermal Kit

Opis szczegółowy produktu

FPV camera CADDXFPV ECLIPSE 006HD Thermal Kit

The CADDXFPV Eclipse 006HD is a cutting-edge thermal FPV camera designed for optimal performance in various conditions. Its high-resolution thermal imaging provides clear and detailed visuals even in low light or complete darkness. It's ideal for FPV pilots who need precise, real-time thermal data during flights. The camera's wide field of view and fast frame rate ensure you capture every moment precisely.

This kit includes the Eclipse 006HD thermal camera, Walksnail Avatar GT VTX, providing seamless video transmission and recording at 1080p and 2 antennas. This combination delivers reliable performance, making it perfect for use in challenging environments.

Specifications:

Model: Eclipse 006
Detector Type: Uncooled Vanadium Oxide
Resolution: 640x512
Wavelength Range: 8-12μm
LENS: F1.0/9.1mm
FOV: 48.3°(H) * 38.6°(V) * 66°(D)
Frame Rate: 50fps
Power Consumption: <1.5W
Output: PAL
Latency: Average delay 22ms
Antenna: 2 (IPEX)
Supply Voltage: 9V-24V
Temperature: -20°C~60°C
Interface: HD Interface: MIPI
Image Quality: Average Latency 20ms, Allimage Enhancement

Model: Avatar GT VTX
Communication Frequency: 5.725-5.850 GHz
Transmitter Power (EIRP): FCC: <30dBm, MAX: 33dBm; CE: <14dBm; SRRC: <20dBm; MIC: <25dBm
Recording: 1080p/720p
Channels: 8
Power (W): 2W MAX
Wide Power Input: 11.1~25.2V
OSD: Canvas mode
Latency: Average delay 22ms
Antenna: 2(IPEX)

Package Includes:
1x CADDXFPV ECLIPSE 006HD Thermal Kit
