FPV Drone iFlight Chimera9 ECO 6S Analog BNF (TBS)

Opis szczegółowy produktu

Chimera9 ECO 6S Analog BNF (TBS)

Features:

- Latest Chimera9 ECO Frame for Maximum Protection.
The new frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts.

- Economic and Efficient Electrical System.
Equipped with the BLITZ ATF435 Flight Controller, BLITZ 1.6W Whoop VTX, and the BLITZ E55S 4-in-1 ESC, this setup offers a high level of power and functionality.

Not included in BNF Lite version:
- Heatsink for DJI O3 Air Unit
- Dual 5.8G VTX Antenna TPU mount
- Anti Spark Filter
- TPU Set (GPS mount/ Buzzer mount/GoPro mount, etc.)
- LED Board with LED Strips

Specifications:

Product Name: Chimera9 ECO 6S Analog
Receiver Option: TBS Crossfire Nano RX
FC: BLITZ ATF435 Flight Controller
ESC: BLITZ E55S 4-IN-1 2-6S 55A ESC
Video Transmission: BLITZ Whoop 1.6W VTX
Geometry: DeadCat(DC)
Frame: 405mm wheelbase
Motor: XING-E 2809 800KV motors
Prop: 9X4X3 propellers
Camera: RaceCam R1 Mini 1200TVL 2.5mm
Weight: 739g (Without Battery)
Dimensions (L×W×H): 360x235x34mm
Max Speed: 140km/h
Maximum Takeoff Altitude: 6000 m
Max Hover Time: Approx. 33 mins (With 6S2P 8000mAh no load)
Operating Temperature Range: -10° to 40° C (14° to 104° F)
Antennas: Single Antennas
GNSS: GPS+SBAS+Galileo+QZSS+Glonass (Optional)
Payload: 1.5-2.2kg

Video Transmission
Product Name: BLITZ Whoop 5.8G 1.6W VTX
Output Power: 0-25-400-800-1600mw
Input Volts: 12V
Working Current: ≤pit @40mA，≤25mw@150mA，≤400mw@330mA，≤800mw@460mA，≤1600mw@660mA
Transmission fre: 40CH(A-B-E-F-R)
Antenna Interface: IPEX
Mounting Hole: 25*25/φ1.6mm
Weight: 16.5g (Antenna not included)
Dimensions: 37*31.5*10mm

Package Includes:
1 x Chimera9 ECO 6S Analog BNF (TBS)
1 x Battery pad
1 x Antenna
2 x Propellers(Pairs)
2 x Battery strap
