Charger ISDT X16 1100W x 2/20A x 2 Dual-Channel Smart

Opis szczegółowy produktu

ISDT X16 Lipo Charger:

Key Features

• High Power Multifunctional Charger:

  • Supports 2-16S LiFe, LiPo, LiHv, and ULiHv batteries, including ultra high voltage lithium batteries (up to 4.45V per cell).
  • Dual-channel parallel charging with a total output power exceeding 2200W.
  • Battery charge and discharge cycles supported, with a maximum discharging power of 50W per channel and a balance current of 1.5A per cell for enhanced battery longevity.

• Bluetooth Connectivity:

  • Connect to mobile devices via Bluetooth for control and monitoring.
  • Use the “ISD Link” app to view detailed parameters for each channel and preset charging tasks for one-click operations. Supports OTA upgrades for easy updates.

• Safety Features:

  • Built-in 1200W independent dual power supply with multiple protections: short-circuit, overload, under-voltage, over-voltage, and over-temperature.
  • Compatible with both AC 120V and AC 220V voltage inputs. Two channels can operate independently or in combination for stable performance.

• Synchronous Parallel Charging:

  • High-speed processor for synchronous balance charging.
  • Maximum parallel charging power of up to 1800W (@220V AC) with charging current ranging from 21A to 35A for rapid charging experiences.

• User-Friendly Display:

  • 2.8-inch IPS LCD screen with auto-brightness adjustment and a 178° viewing angle for clear visibility in various lighting conditions, including bright sunlight.

Specifications

• Input Voltage: AC 100-240V
• Output Voltage: DC 10-72V
• Charging Current: 1.0-20.0A per channel (×2)
• Discharging Current: 0.5-3.0A per channel (×2)
• Max Charging Power: 1100W per channel (@220V AC) / 800W per channel (@110V AC)
• Max Discharging Power: 50W per channel
• Balance Current: 1.5A per cell
• Supported Battery Types:
  • LiIon, LiFe, LiPo, LiHv, ULiHv (2-16S)
• Alarm Features: Abnormal voltage and incorrect cell count setting alarms
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -20°C to 60°C
• Dimensions: 276 x 246 x 82 mm
• Weight: Approximately 4.5 kg
• Connector Type: XT90i

Package Includes

• 1 x ISDT X16 Lipo Charger
