FPV Camera CaddxFPV Caddx Ant (Black 4:3)

Opis szczegółowy produktu

Caddx Ant (Black 4:3)

The Caddx Ant Nano Camera is a 14x14mm ultralight budget-friendly camera that only weighs 2g and supports OSD Menu, 3.7-18.V, Global WDR, NTSC or PAL, and CVBS video output. A unique feature of this camera is that it includes 3D DNR, which gives you a full clarity image, so there is no need to worry about your image looking grainy or noisy when flying. To fit bigger builds, you can mount the Nano into a 19mm bracket (included).

Specifications

Model: Caddx Ant Nano Camera
Image: 4:3
Color: Black
Electronic Shutter: PAL: 1/50-100, 000; NTSC: 1/60-1000, 000
Dimensions: 14x14mm (with a bracket to 19x19mm)
TV System: NTSC & PAL (Changeable)
Image Sensor: 1/3" CMOS Sensor
Min. Illumination: 0.001Lux@F1.2
Horizontal Resolution: 1200TVL
Work Temperature: -20°C +60°C
Wide Power Input: DC 3.7-18V
S/N Radio: >52dB (AGC OFF)
Work Humidity: 20% - 80%
Synchronization: Internal
Auto Gain Comtrol: Yes
Video Output: CVBS
WDR: Global WDR
Weight: 2g (N.W.)
Menu: Support
DNR: 3D DNR
Fov: 165°
Lens: 1.8mm
BLC: Yes

Package Includes:
1x Caddx Ant FPV Nano Camera
1x 3pin FPV silicone cable
1x 5D-OSD Menu Board
1x FPV Silicone Cable
1x Warranty card
1x 19mm bracket
4x Screws
