Motor SunnySky V2 X2216 1100KV

Detailní popis produktu

Motor SunnySky V2 X2216 1100KV:

The SunnySky V2 X2216 1100KV motor features a CNC-milled, hollow-designed body for optimal heat dissipation and reduced weight, giving it a robust visual appeal. It includes a high-strength 420 stainless steel shaft, ensuring durability and resistance to bending. The motor’s top and bottom caps are crafted from 6061-T6 aviation aluminum alloy for added strength. Equipped with imported NMB mini bearings, this motor offers quiet, stable operation and extended life. Hand-wound coils enhance efficiency and power output. Note: This is the short shaft version.

Specifications:

Motor Model: X2216
KV: 1100Kv
Stator/Rotor Poles: 12N14P
Internal Resistance: 54mΩ
Motor length: 34mm
Shaft Diameter: 3.175mm
AWG: 20AWG 100mm
Motor Weight (wire included): 69g
Rated Operational Voltage: 2-4S
No-load Current: 0.8A
Maximum Continuous Power: 480W
Maximum Continuous Current: 34A/30s
ESC Recommended Use: 30-40A
Propeller Size Recommended Use: APC9047, APC9045, APC11x4.7, APC1047, APC8060

Package Includes:
1x Motor SunnySky V2 X2216 1100KV
