FPV Drone GEPRC MOZ7 O3 GPS ELRS915

Product detailed description

MOZ7 O3 GPS ELRS915

MOZ7 supports a maximum of 30.5mm×30.5mm stack installation and is compatible with various VTX and customized cooling systems. Innovative camera fixing method, the left and right alternate camera aluminum parts installation position can realize the switching between 19mm and 20mm size. The fixed point of the camera is reinforced with a carbon plate to make the installation force more uniform and avoid warping and deformation.

Use the SPAN F722-BT-HD V2 stack, and support Bluetooth wireless parameter adjustment. The 2809 motors with HQ7.5*3.7*3 propellers are powerful. At the same time, it is equipped with GEP-M10-DQ GPS to protect long-distance flight. The front receiver antenna prevents the fuselage from blocking the receiver signal due to a U-turn in the air.

Use the GEP-VTC6-6000mAh battery to fly for 30 minutes, and the GoPro 10 to fly for 20 minutes. Choose the DJI O3 version for in-camera recording that supports up to 4K 120FPS to meet your daily shooting needs.

Features:
1. The camera uses CNC aluminum alloy side plate, strong and sturdy, compatible with 19mm and 20mm camera mounts.
2. The flight controller has built-in Bluetooth, mobile phone wireless connection, convenient and fast parameter adjustment.
3. Personalized protective side plate, effectively protects the safe operation of internal electronic equipment and improves flight reliability, the maximum support for 30.5×30.5mm stack and 30mm*30mm video transmission (outer size) installation.
4. Adopt DJI O3 VTX, FPV image is clear, stable signal, low delay, long distance, and supports up to 4K/120fps recording.
5. Compatible motor hole position, support 16mm×16mm and 19mm×19mm motor installation.
6. Added VTX cooling fins to ensure stable operation during flight.

Specifications:

Model: MOZ7
Frame: GEP-MOZ7
Dimensions: 280mm×310mm
Wheelbase: 320mm
Top plate: 3.0mm
Bottom plate: 3.0mm
Arm plate: 6.0mm
Splint plate: 3.0mm
Camera mount: 2.0mm
VTX cover: 1.5mm
FC: SPAN F722-HD-BT V2
MCU: STM32F722
Gyro: 42688-P (SPI)
VTX: O3 Air Unit
ESC: GEP-BLheli32-50A
Propeller: HQ7.5*3.7*3
Antenna: Momoda 5.8G RP-SMA LHCP 120MM
Motor: 2809-1280KV (6s version)
GPS: GEP-M10
Camera: DJI O3 Air Unit
Weight: 700.5g
Receiver: ELRS 915M
Recommended battery: VTC6 6S 6000mAh / LiPo 6s 3300mAh
