Frame GEPRC GEP-CT30

Product detailed description

GEP-CT30

The GEP-CT30 frame specially developed by GEPRC team for cinematic enthusiasts.

As a cinematic FPV frame, the new series of GEP-CT30 frame uses a high-precision 7075-T aircraft-grade aluminum alloy bracket for FPV camera escort. The newly polished gimbal damping module can easily fix high-frequency vibration and jello issues. It can be mounted with multiple action cameras which have stable and clear images, and it’s easy to film. GEP-CT30 frame supports the installation of mainstream AIO flight controllers with 25.5mm*25.5mm mounting holes and is compatible with various VTX mounting holes on the market such as 20mm*20mm/25.5mm*25.5mm. With 12mm * 12mm motor mounting holes, can be installed with larger 15-18-20 series motors, with strong power output with 3-inch propeller. Ultra-light fuselage weight for more confident flying.

Adopts high-strength one-piece injection-molded propeller guard and high-toughness and impact-resistant PC material for injection molding. A ring-shaped Cob light strip is embedded in the propeller guard, and the light effect is carefully tuned. Light strip kits are optional for flexible options. 7075-T aircraft-grade aluminum column, finely polished frame design, only 6 screws need to be removed to separate the aircraft top plate and propeller guard. Easy to cope with the urgent need to replace the accessories, at any time to restore the state.

Specification
Brand: GEPRC
Model: GEP-CT30
Motor to Motor: 127mm
Isolation Plate: 2.0mm
Main Plate: 3.0mm
Bottom Plate: 1.5mm
FC Mounting Hole: 25.5mm x 25.5mm
VTX Mounting Hole: 20mm x 20mm /25.5 x 25.5
Motor Mounting Hole: 12mm x 12mm
FPV Camera Spacing: 19mm
Suitable Propeller Size: 3-inch propeller
Weight: 103.2g (including propeller guard, 3D printed parts, Naked GP8 camera base mount, antenna tube)
