FPV Drone iFlight Nazgul XL5 ECO Analog BNF 6S TBS

Product detailed description

FPV Drone iFlight Nazgul XL5 ECO Analog BNF 6S TBS

Nazgul XL5 ECO - the 5-inch standard Freestyle drone that redefines performance and value. Featuring an ATF435 flight controller, BLITZ 1.6W VTX, and BLITZ E55S 2-6S 55A ESC, the Nazgul XL5 ECO delivers unparalleled performance and reliability. The carbon fiber with aluminum camera mount offers lightweight durability, while the included GoPro mount provides versatility for capturing your epic freestyle flights.

Features

- Lightweight and Durable: Constructed from carbon fiber and aluminum, providing a strong yet lightweight structure for camera equipment. Ensures clear video without propeller obstruction.
- Anti-Spark Filter: Feature a protective circuit to prevent sparks and extend the lifespan of XT60 connectors, protecting electronics from voltage or current spikes.
- Enhanced User Experience and Maintenance: Includes a built-in buzzer and receiver mount for easy maintenance and receiver adjustments.
- DIY Customized Space: Offers 20x20 and 30.5x30.5 mounting holes for compatibility with popular flight stacks and VTX systems, allowing for personalized setup and seamless integration.

Specifications:
Product Name: Nazgul XL5 ECO 6S Analog
Geometry: True-X
FC: BLITZ ATF435 Flight Controller
ESC: BLITZ E55S 4-IN-1 ESC
Video Transmission: BLITZ 1.6W VTX
Receiver option: TBS Crossfire NANO RX
Frame: 245mm wheelbase
Motor: XING-E Pro 2207 1800KV motors
Prop: Nazgul F5 propellers
Weight: 427g
Takeoff Weight: Approx. 652g (With 6S 1400mAh battery)
Dimensions (L×W×H): 173×173×34±2 mm
Diagonal Distance: 245mm
Max Speed: 190 km/h (Manual Mode)
Maximum Takeoff Altitude: 3200 m
Max Hover Time: Approx. 7.5 mins (No Load with 6S 1400mAh Battery)
Max Wind Speed Resistance: Level 7
Operating Temperature Range: -10° to 40° C (14° to 104° F)
Antennas: Single Antenna
GNSS: GPS+SBAS+Galileo+QZSS+Glonass (Optional)

Video Transmission:
Product Name: BLITZ 5.8G 1.6W VTX
Output Power: 0-25-400-800-1600mw
Input Volts: 7-34V(2-8S)
Working Current: 25.2V, ≤pit @20mA, ≤25mw@65mA, ≤400mw@130mA, ≤800mw@150mA, ≤1600mw@250mA
Transmission fre: 40CH(A-B-E-F-R)
Antenna Interface: MMCX
Mounting Hole: 30.5×30.5/Φ3mm
Weight: 18.9g (Antenna not included)
Dimensions: 38.5×38.5mm

Package Includes:
1 x Nazgul XL5 ECO 6S Analog BNF (TBS)
1 x Antennas
2 x Battery pads
2 x Nazgul F5 Prop(Pairs)
