FPV camera Foxeer Predator V5 Nano Black

Product detailed description

FPV camera Foxeer Predator V5 Nano Black

The Sony 1/3" CMOS Switchable FPV Camera combines high-resolution imaging with flexible settings, making it a perfect choice for pilots seeking versatility and performance in a compact package. Designed for seamless adaptation to different lighting conditions and aspect ratios, this camera is ideal for both racing and freestyle drones.

Key Features:

• Sensor: Sony 1/3" CMOS for excellent image quality and clarity.
• Resolution: 1000TVL for detailed analog video output.
• Aspect Ratio: Switchable between 4:3 (default) and 16:9 for customizable viewing preferences.
• TV System: PAL (default) and NTSC modes switchable to match your setup.

Imaging Capabilities:

• Field of View (FOV):
  • Horizontal FOV (FOV-H): 125°.
  • Diagonal FOV (FOV-D): 155°.
• Low Light Sensitivity: 0.01 Lux for reliable performance in dark environments.
• Dynamic Range: Super WDR for excellent handling of high-contrast scenes.
• Noise Reduction: 3DNR and 2DNR for cleaner and sharper visuals.
• Customizable Modes:
  • Day, Cloudy, Night, and LED.
  • Fast mode switching with a long press of the right button.

Functional Enhancements:

• Flight OSD: Displays voltage, camera title, flight time, and crosshair for improved situational awareness.
• Flip Mode: Supports video flipping for versatile mounting options.
• Shutter Speed:
  • PAL: 1/25–1/10000 sec.
  • NTSC: 1/30–1/10000 sec.

Build and Power:

• Power Input: Wide range of 4.5V–20V for flexible installations.
• Power Consumption:
  • 50mA ± 15% @ 12V.
  • 115mA ± 15% @ 5V.
• Compact and Lightweight:
  • Dimensions: 14 × 14mm; 19 × 19mm with bracket.
  • Weight:
    • Plug: 4.8g.
    • Solder Pad: 4.3g (excluding cable).

Durability and Language Support:

• Operating Conditions:
  • Temperature: -10° to 50°C, up to 90% humidity.
  • Storage: -20° to 70°C.
• Language Options: Supports multiple languages, including English, German, French, Portuguese, Spanish, and Chinese.
