ESC Flycolor Trinx G5 60A 4-in-1

Code: W4-FW060006-G1G1-TX1
Not rated
Brand: Flycolor
€104,88 €86,68 excl. VAT
In stock (9 pcs)
Delivery to:
26/11/2024
Delivery offer

Detailed information

Product detailed description

ESC Flycolor Trinx G5 60A 4-in-1

The Flycolor Trinx G5 60A 4-in-1 ESC is a high-performance electronic speed controller designed for demanding quadcopter setups. It supports a continuous current of 60A and a burst current of 70A, making it ideal for power-hungry drones. The ESC operates on 3-6S LiPo batteries and features BLHeli32 firmware, ensuring fast response and minimal latency. Its compact design, weighing just 19.6g, makes it suitable for various drone configurations

Features:
- PWM frequency up to 128K.
- Multiple Protocols.
- 4in1 ESC built-in current sensor and VBAT output.
- Longer and better performance thanks to its large surface area of aluminum heat sink.
- Damping design to reduce the effect of vibration on the flight controller.
- Supports higher power load.
- Large soldering tabs.

Specifications:
Model: Trinx G5 4in1
Con. Current: 60A
Burst Current(10S): 70A
BEC: NO
LiPo cells: 3-6S
Weight: 19.6g (with heat sink)
Size: 45x41x8.3mm
Mounting: 30.5x30.5 (M3)
Configurator: BLHeliSuite32
Firmware: Flycolor_Raptor_5
All D-shot, Pro-shot
MCU: STM32G07

Package Includes:
1x  Trinx G5 4in1- 60A ESC

Additional parameters

Category: ESC
Continuous Current: 60A
ESC Type: 4-in-1
Mounting Size: 30.5x30.5mm
Power Supply: 3-6S
