Antenna Maple Wireless 5.8G 2dBi Omnidirectional RP-SMA (14cm)

Code: P005-RP-14
Not rated
€9,68 €8 excl. VAT
Upon request
Delivery offer
The item has been sold out…

Detailed information

Product detailed description

5.8G 2dBi Omnidirectional Antenna RP-SMA (14cm)

The 5.8G 2dBi Omnidirectional Antenna is designed to enhance signal transmission and reception for devices operating in the 5.8GHz frequency band. With its omnidirectional design, it can receive signals from multiple directions, providing reliable connectivity in all orientations. Its 2dBi gain ensures improved signal strength and stability for wireless communication applications.

Specifications:

Frequency range (MHz): 5660-5914
Polarization: RHCP
Gain (dBi): 2 dBI
Input impedance: 50
Maximum input power (W): 50
Beam Half Power: 360° H-plane 95° E-plane
Input Connector Type: RP-SMA
Dome Material: ABS
Dome Color: Black (RHCP)
Length: 140mm
Size: head size 13*15MM

Package Includes:
1x 5.8G 2dBi Omnidirectional Antenna RP-SMA (14cm)

Additional parameters

Category: VTX Antennas
Connector Type: RP-SMA
Frequency: 5.8GHz
Length: 140mm
Polarization: RHCP
