AIO FC GEPRC GEP-F411-35A
Artikelnummer: GP104683Detaillierte Produktbeschreibung
GEP-F411-35A AIO Der GEP-F4-35A ist eine verbesserte Version des GEP-F4-20A, die für 35A Dauerstrom (40A Burst) ausgelegt ist und 2-6S-LiPo-Akkus voll unterstützt. Es ist mit einer Reihe von Motoren und Propellern kompatibel, was es vielseitig für verschiedene Drohnenkonfigurationen macht. Das AIO-Board verfügt über eine OSD-Parametereinstellung, ist mit 8,8 g leicht und hat 25,5 mm * 25,5 mm große Befestigungslöcher, die für die meisten Rahmen geeignet sind. Spezifikationen: Modell: GEP-F411-35A AIO MCU: STM32F411 IMU: BMI270/Beschleunigungsmesser (SPI) Ziel: GEPRC_F411_AIO OSD: Betaflight OSD mit AT7456E Chip UART-Anschlüsse: T1 R1 / T2 R2 Signalton: YES LED: JA USB-Anschluss: micro USB ESC MCU: 8BB21F16G Integrierter LC-Filter Kontinuierlicher Strom: 35A Burst-Strom: 40A (10s) Eingangsspannung: 2-6S (LiPo-Akku) ESC-Protokoll: Dshot300/600, Oneshot, Multishot Blackbox: 16Mb ESC Ziel: G_H_30 BLS Größe: 32x32mm Platine Befestigungslöcher: 25.5×25.5mm Gewicht: 8.8g
Zusätzliche Parameter
Kategorie: | AIO FC |
---|---|
Power Supply: | 2-6S |
Continuous Current: | 35A |
Motor Size: | 25.5×25.5mm |
Processor Type: | F411 |
Dieser Artikel ist leider ausverkauft… |
Seien Sie der Erste, der einen Beitrag über diesen Artikel schreibt.
